Learning how to build your lightsaber reserves your place in the galaxy of crafting warriors. It allows you to wield a piece of the universe’s most elegant weaponry customized to your unique vision. Whether you align with the noble Jedi or find the allure of the Dark Side irresistible, this project guides you through creating a Duel-Worthy Lightsaber. With a lightsaber at your side, you’re not just embracing the Force; you’re forging a bond with a weapon that tells your story.
How To Build A Lightsaber
Materials List:
The Blade:
- 1 x Polycarbonate (PC) tube, 30-36 inch long, 1 inch OD, 1/8 inch wall thickness
- 1 x End cap for the PC tube (blade tip)
- 1 x Reflective material, smaller than the ID of the PC tube
- 1 x Blade film (e.g., “Corbin” film)
The Hilt:
- 1 x Blade/LED holder (emitter)
- 1 x Chrome sink tube, 1.5 inch, 12 inches long
- 1-2 x Sink tube adapter
- 1 x Button or switch
- 1 x Pommel or end cap
- Various decorative elements for customization
The Electronic Guts:
- 1 x High power LED (e.g., Luxeon III, K2, V, Rebel)
- 1 x Compatible optical lens
- 1 x Current control method (e.g., BuckPuck)
- Optional sound components (Hasbro toy board, speakers, soundboard, etc.)
- Batteries, battery holder, wires
Tools Needed:
- Soldering iron (45 watts or higher)
- Hack saw
- Rotary tool (e.g., Dremel)
- Drill and drill bits
- Jeweler’s files
- Screw tap set
- Screwdrivers
- Allen wrenches
- Hammer
- Metal or epoxy glue
- Elmer’s glue
- Graph paper
- Pencil and Sharpie
- Sandpaper (coarse and fine assortment)
Crafting Your Lightsaber: Step by Step
Design Planning: Before diving into the build, envision your lightsaber’s appearance. Consider blade color, hilt length, and overall aesthetic. Utilize tools like the Modular Hilt System (MHS) Builder to visualize and fine-tune your design, ensuring a comprehensive parts list tailored to your vision.
Assembling the Blade: Your blade consists of a polycarbonate tube, an end cap, a reflective disk, and a light diffusion film. These elements combine to create a sturdy, luminous blade that not only stands up to spirited dueling but also brilliantly captures the essence of a true lightsaber’s glow.
Crafting the Blade Holder: The emitter, or blade holder, is crucial as it secures the blade and houses the LED and optics. It also acts as a heatsink. When choosing or crafting your blade holder, ensure it aligns with your desired aesthetic while functioning efficiently to prevent your LED from overheating.
Constructing the Hilt Body: The hilt is the heart of your lightsaber, offering endless opportunities for personalization. Whether you opt for a sleek, minimalist design or intricate decorations, this is where your lightsaber truly becomes your own. Incorporate grips, trim, and other elements that reflect your unique style.
Installing the Electronic Guts: The electronics bring your lightsaber to life. Carefully integrate the LED, lens, and current control method into your hilt. Optionally, adding sound components will enrich your lightsaber with the iconic hums and crackles that make dueling even more immersive.
